AUTOCLAVE RECTANGULAR HORIZONTAL

MODEL NO. : GTA-004

• Construction Robust and rugged all weld construction which is leak proof unlike riveted construction. Inner chamber is made of thick plate of stainless steel of 304/316 quality and jacket is made out of rolled steel.
• Sterilizers will have single door made out of rolled steel lined with STAINLESS STEEL. sheet on both sides.
• All the sterilizers are hydraulically tested to withstand 2.5 times the working pressure.
• The steam jacket is lined on the outer side with asbestos sheet or glass wool which prevents heat losses due to radiation and is covered by strong rolled steel sheet duly painted.
• Boiler Made of thick stainless steel plate suitably located under the sterilizer. High grade flanged type heating elements are fitted from front side for easy replacement/repair.
• Fitted with water gauge glass for water level, safety valve, water inlet and drain valves.
• It is also provided with Low Water Level cut off device. This device protects the heater in the generator from burning out dry.
• All units are hydraulically tested upto 40psi.
• Drain valve is fitted at the side bottom for easy draining/cleaning.
• Triple walled with Steam Jacket and Separate Boiler. Sterilization cycle is controlled by Multiport Valve. The unit is fitted with all standard accessories.
• To work on 440volts 3 Phase A.C. Supply
